AnDVB-S111

Regular options

OS	Android 10
Interface	Android TV
Chipset	Allwinner H616
Memory	EMCP 2/16
Display	+
Voice remote control	+
L1 Widevine	+
Netflix	ATV (HD)
Secure Image	+
Stalker APK	3
MPEG-4	+
HD	+
HEVC	+
UHD	+
DVB-S2x	+
DVB-T2/C	-
CA	+
CI	+
CI+	+
Wi-Fi 2.4/5.0	Allwinner SV859, Wi-Fi 5, Channel width 80 MHz (Link 390 MBit/s)
Bluetooth	5.0 (8052 Chip)
Lan	+
USB	2
HDMI	+
AV	Jack
s/pdif	+
ESD protection	Optional

R.A.M.F. options

Sat Finder	Possible R&D within 2 months. Implemented for R.T.O.S. stb
Spectrum	Possible R&D within 2 months. Implemented for R.T.O.S. stb
3D R.A.M.F. LNB support	Possible R&D within 2 months. Implemented for R.T.O.S. stb
Reports with signal parameters	Possible R&D within 2 months. Implemented for R.T.O.S. stb
Remote diagnostics (sending the report to the operator/installer)	Possible R&D within 2 months. Implemented for R.T.O.S. stb
Fix-it-yourself instructions	Possible R&D within 2 months

Measurements

Spectrum	Possible R&D within 2 months. Implemented for R.T.O.S. stb
RSSI	Possible R&D within 2 months. Implemented for R.T.O.S. stb
SNR	Possible R&D within 2 months. Implemented for R.T.O.S. stb
PER	Possible R&D within 2 months. Implemented for R.T.O.S. stb
LM	Possible R&D within 2 months. Implemented for R.T.O.S. stb
Output voltage	Possible R&D within 2 months. Implemented for R.T.O.S. stb
Signal interference	Possible R&D within 2 months. Implemented for R.T.O.S. stb
Antenna vibration	Possible R&D within 2 months. Implemented for R.T.O.S. stb
Voltage in the cable	Possible R&D within 2 months. Implemented for R.T.O.S. stb
22kHz control signal attenuation	Possible R&D within 2 months. Implemented for R.T.O.S. stb

DVB2IP Bridge options

We are ready for cooperation

Open Web API	Possible R&D within 2 months. Implemented for R.T.O.S. stb
Watching DVB without TV set	Possible R&D within 2 months. Implemented for R.T.O.S. stb
APK for Android	Possible R&D within 2 months. Implemented for R.T.O.S. stb
